Grizzly® Compact Tractor Tine Grapple

Specification

• Grizzly®
• Compact Tractor Tine Grapple

• Skid Steer Type Mount
• Product Number: 811850
• Can be used on up to 38 HP tractors
• Overall Width: 48"
• Mount Type: Skid Steer
• Overall Height Closed: 32.75"
• Grapple Opening: 33"
• Upper grapple Width: 31"
• Lower Grapple Width: 48"
• Tine Spacing: 7.5"
• Number of Tines/Grapples (lower and upper): 7/4
• Reinforcing Tubes Between Lower Tines: Yes
• Number of Hydraulic Cylinders:1
• Cylinder Size: 2" x 8"
• Upper grapple, lower tines have gripping notches to help retain loose materials
• Greaseable pivot points for long service life
• Shipped less hoses & fittings, allowing the dealer to correctly match the hose length to the tractor / loader
• Tractor remote hydraulic ports are required to operate the grapple
