14 In. Disc Hiller with 16 In. Shank, King Style Hub

This 14 in. disc hiller with a 16 in. shank is used to cover seedbeds, as well as create them. The King style hub comes complete with 6 square bolts, each 1/4 in. wide and it is built to resist weathering. Use two steel disc assemblies to easily move soil efficiently in one pass.
Availability:
#36358
Product Overview

Use a disc hiller assembly to create raised garden and seedbeds or bury ground crops such as potatoes and carrots. This 14 in. bed shaper can be used in a series of two attached to a tool bar to achieve the desired mounds on the field. This steel disc is equipped with a King style hub including a six bolt mounting 4-1/4 in. pattern. Each King hub is assembled to resist the wear and tear of continuous use and the elements.


The rugged 16 in. shank connected to the bed shaper is also forged of steel and is 1-3/16 in. in diameter. Adjust the width of the hilling discs assemblies for your specific requirements.


Specifications

  • 14 in. disc hiller with 16 in. shank
  • Shank diameter: 1-3/16 in.
  • Steel construction
  • King style hub with 6 holes
  • Hub hole spacing 1/4 in. square bolts on 4-1/4 in. pattern
Blanton Style Disc Hiller
Product
Number

Ref #

Description
Qty
Required
11678216" Shank (1-3/16" rd)1
30336222" Shank (1-3/16" rd)1
357403Hub - No Bearings1
178614206 GGH Bearing1
80970512" Blade 3 MM1
80971514" Blade 3 MM1
80973516" Blade 3 MM1
824036Snap Ring1
1309973/4" Lock Washer1
1310983/4" Hex Nut1
3395593/4" Flat Washer2
29842103/4" x 3-1/2" Thin Head Bolt1
13103111/4" Hex Nut6
13093121/4" Lock Washer6
n/a131/4" Ribbed Bolt6

Should this product not fit your requirements, tool bar, or tractor, we carry a variety of disc hillers to offer.
