King Kutter® Rotary Tiller, Gear Driven, 7'
Item #76683
This tillovator by King Kutter, TG-84-YK, is designed and built to be dependable. The 3-point rotary tiller has 11 flanges with 6 L-shaped tines on each flange. With a total of 66 tiller tines, the tillovator has a maximum soil penetration of 8 inches. The all gear drive is protected with the PTO slip clutch and is easy to maintain.
Product Overview
The King Kutter® II has an 84 inch working width and a working depth of 8 inches. Designed with heavy duty square tube framing and cast iron center and gear drive side gearbox, this tillovator will perform year after year. Made to King Kutter® standards, this rotary tiller includes a PTO equipped with a slip clutch to protect the gearbox.
Specifications:
- King Kutter® TG-84-YK
- Gear Driven 3-Point Rotary Tiller, 7 Feet
- Tractor HP requirements: 50 to 65 HP
- Working width: 84 inches
- Maximum tilling depth: 8 inches
- Straddle Hitch
- Rotor shaft speed (RPM): 210 at 540
- Rotor drive: all gear driven
- Gearbox protection: slip clutch
- Number of flanges: 11
- Tines per flange: 6
- L-Shaped tine spacing 7-1/2 inches
- PTO category: 4
- PTO shaft replacement, ASC #40944 or #89364
- Hitch: Category 1 or 2
- Weight: 890 lbs.
- Replacement 1 LH and 1 RH blades with nuts and bolts, ASC #52429
We carry a wide selection of Tillovators to fit your tractor and your budget.
