PTO Shaft, 32-3/4" Closed
Item #33029
This PTO shaft helps evenly distribute the engine power of your series 5 tiller machine. Overall the length measures 32.8 inches, and from center to center cross member measures 24 inches. It also comes equipped with a yoke on either side and they both have 6 splined.
Product Overview
A PTO driven rotary tiller must have a strong working drive shaft in order to transmit the engine power. This PTO shaft is designed for medium duty tillers. The extended length when the yokes are attached measures 32.8 inches long. The spline yoke on the tractor end and on the implement end both measure 1-3/8 inches with a 6 splined interior. All parts are included with this PTO shaft.
Specifications- PTO Shaft
- Series 5
- To fit, medium duty tillers, PTO generator
- Overall length: 32.8 in.
- Safe extended length: 43.8 in.
- 47 HP at 540 RPM
- 72 HP at 1000 RPM
- Length center to center cross member: 24 in.
- Splined yoke on both ends
- Implement end: 1-3/8 in., 6 spline
- Tractor end: 1-3/8 in., 6 spline
- Max HP 540-1,000 - 47/74
