With 6 HP, the 2 inch S-series Ag Pacer Pump is a powerful agricultural pump designed for heavy use. Featuring a 208cc overhead valve engine, this Pacer Pump can pump large amounts of liquids, water, and chemicals in a variety of applications, including agricultural and dewatering uses. The S-series Ag Pump features a self-priming pump. This model formerly had a yellow motor, the only change was the paint color.

Like all Pacer Pumps, this agricultural pump is built to last. The volute, the impeller, and the housing are all built using corrosion resistant glass reinforced polyester. The shaft seal and internal fasteners are stainless steel, and the face of the shaft seal has a carbon and ceramic face that is designed to extend its longevity. The external fasteners are plated steel. All rubber used is EPDM rubber so it can be used with chemicals necessary for farming.

This powerful 6 HP agricultural pump features a 2 inch inlet and outlet with a built-in check valve, a maximum flow rate of 160 GPM, and a maximum head of 120 feet. With fast suction, this Pacer Pump can lift to 25 feet. The maximum shut off pressure is 50 PSI, which increases the pumping distance and sprinkler head applications. Other features include a 3.8 quart fuel tank, an electronic ignition, a cast iron cylinder sleeve, and low oil shut off to protect your engine.

Specifications

• 6 HP (formerly yellow motor and now black)
• 3,450 RPM
• 43-46 PSI
• LCT 208cc overhead valve engine
• 3 vane impeller
• 2 inch NPT port
• 120 foot (max 50 PSI) max TDH
• Max flow at 160 GPM
• Corrosion resistant polyester for use with Nitrogen, Round-Up, Atrazine and many other chemicals
• Stainless steel internal fasteners and EPDM elastomers
• Maximum shut off pressure 52 PSI for increased pumping distance and sprinkler head applications
• Fast suction lifts to 25 feet
• Dual air filter
• 3.8 quart fuel tank
• Electronic ignition
• Cast iron cylinder sleeve
• Low oil shut off for engine protection
• Important to use 8 to 10 wraps of teflon tape on fittings as the threads are deeper than common pipe threads
• For Recoil Assembly use ASC # 132540
