Agri-Fab Wheel Assembly 44930 Fits 30" & 38" Lawn Sweepers
Agri-Fab lawn sweepers are top of the line using durable brushes to remove leaves, grass clippings, and more from your lawn. Agri Supply carries replacement wheel assemblies like this one for 30 or 38 inch sweepers, or you can find assemblies for 42 and 46 inch lawn sweepers here.
Specifications- Fits 30" and 38" Agri-Fab Lawn Sweeper (may not fit other brands)
- Axle size: 5/8"
- Bearing OD: 1-1/16"
- Comes with bearings
- Rim OD: 8-1/4"
- OD of wheel: 10"
- Teeth: 50
- OD of the ring of teeth: 5-1/8"
- Width of tire: 1-5/8"
- Tire sidewall: 7/8"
- Fits Agri Fab 30" sweepers only molel:
- 45-0219, 45-0337
- 38" Agri Fab sweepers only model:
- 45-0331, 45-0376
I have a mid 80's era Sears/Craftsman 30 lawn sweeper which recently gave out totally as a result of worn-out wheels. I appreciate the detailed dimensions of the wheel assembly on the Agri Supply WEB site, and I could compare what I had with this potential replacement. There was a high degree of compatibility (diameter of the wheel that drives the sweeping action, overall wheel diameter, number of teeth). Not as compatible with the dimensions associated with the axle. I measured 0.6 in on my Craftsman sweeper and the 5/8 in specified by Agri Supply. I realized that I should be able to find a "bushing". Immediately after receiving the replacement wheels, I found that a short piece of 1/2 in copper pipe came very close: there was still a small wiggle, but I could not make the drive jump over a tooth. Now it is a matter of keep using it, until it fails again.... More detailed pictures are available from the author. — Henri from WA
